Dynamic Contact Resistance

Advanced Diagnostic Capabilities:

The DCRM System performs real-time resistance measurements of circuit breaker contacts during opening and closing operations. It detects abnormalities in contact travel, timing, and resistance patterns, offering early warning signs of mechanical wear or electrical deterioration that conventional timing tests may miss.

User-Friendly Operation:

Featuring an intuitive interface and advanced analysis software, the DCRM System simplifies complex diagnostics. Automated test sequences and easy-to-interpret graphical outputs allow for fast setup and efficient evaluation, significantly reducing testing time and operator workload.

High Accuracy and Sensitivity:

Built for precision, the DCRM System uses high-speed data acquisition and micro-ohm level resolution to detect even minute variations in contact resistance. This level of detail is essential for identifying issues like contact pitting, improper seatings, and high-resistance joints that could lead to future failures.

Comprehensive Testing Applications:

Suitable for a wide range of circuit breakers including SF₆, vacuum, and oil types, the DCRM System is indispensable for commissioning, maintenance, and condition-based monitoring. It supports testing of all voltage classes, from medium- to extra-high-voltage circuit breakers, across substations, utilities, and industrial facilities.

Compact and Field-Ready:

Engineered for field use, the DCRM System is compact, rugged, and portable, making it easy to deploy in challenging environments. It integrates seamlessly with other breaker test sets, offering enhanced diagnostic capability without added complexity.

Expert Technical Support:

When you rent the DCRM System from [Your Company Name], you gain access to our team of experienced engineers and support professionals. We provide comprehensive assistance—from equipment setup to test interpretation—ensuring efficient and accurate diagnostics every time.

Trusted by Circuit Breaker Experts:

The DCRM System is widely adopted by transmission and distribution utilities, OEMs, and service providers. Its ability to accurately assess breaker contact condition without dismantling the equipment makes it a vital part of predictive maintenance strategies worldwide.

Key Features:

• High-speed dynamic resistance measurement of main and arcing contacts during operation

• Graphical analysis of resistance signatures to identify contact wear, misalignment, and erosion

• Integration with breaker timing and motion analyzers for comprehensive diagnostics

• User-friendly software with automated test routines and report generation

• Portable and rugged design for field testing under various environmental conditions

• Applicable to all breaker types and voltage levels, including SF₆, vacuum, and oil circuit breakers

• Non-invasive diagnostics for early fault detection without breaker disassembly

The Dynamic Contact Resistance Measurement (DCRM) System is a state-of-the-art solution designed to evaluate the condition of circuit breaker contacts during operation. By measuring the resistance profile of the main and arcing contacts throughout the entire operating cycle, the DCRM system provides critical insight into contact wear, misalignment, erosion, and mechanical issues. This advanced testing solution is ideal for ensuring the reliable performance and longevity of high-voltage circuit breakers.
